一眼レフ用特殊交換レンズ Close-up shot lens, GOKO LZ3-2

Close-up shot lens, GOKO LZ3-2

Close-up shot lens for SLR, GOKO LZ3-2, easily takes quality close-up shots of flat objects. Does not require focusing, extra lighting, or a tripod. Can be mounted on both digital and film SLR cameras
    • lz3-2-f2.png
    • lz3-2-f3.png
    • lz3-2-f4.png
    • lz3-2-f5.png
    • lz3-2-f6.png
    • Makes it possible for anyone to easily take high-quality close-up shots
    • Useful close-up shot lens for criminal identification
    • Suitable for documenting details in objects such as currency and historical documents
    • MADE IN JAPAN
  • Features

    • Makes it possible for anyone to easily take high-quality close-up shots
    • Suitable for documenting details in objects such as currency and historical documents
    • Provides magnification of 5× to 15× *
    • Features high-luminosity LED ring (Color temperature: approx. 5,500). No extra lighting required
    • Does not require focus adjustment
    • Can be mounted on both digital and film SLR cameras

    *Print size: 3.5 × 5 inch (Japanese standard photo size) / Image sensor: APS-C

  • Specifications

    LZ3-2 Photographing lens unit

    Model LZ3-2
    Focus System Fixed focus system that is always in focus at the top of the lens hood
    Lens: focal length f = 30 mm
    Zoom 0.8× to 2.4× (on 35-mm film)
    1.3× to 3.8× (on image sensor of APS-C)
    Photographic Coverage 0.80×: 29.42 mm × 43.86 mm (on 35-mm film)
    2.4×: 10.44 mm × 18.83 mm (on 35-mm film)
    0.80×: 18.2 mm × 27.4 mm (on image sensor of APS-C)
    2.4×: 6.5 mm × 9.7 mm (on image sensor of APS-C)
    Compatible Mounts Bayonet mount lenses, Canon (EF), Nikon (F), and Pentax (K)
    Operating Temperature 0℃ to +40℃
    Dimensions Total Length: 86 mm
    External diameter of lens barrel: φ65 mm
    External diameter of lighting unit: φ89 mm
    Weight 330 g
    Standard Attachments 1.Pressing Ring (effective for pressing objects during shooting)
    2.AC adapter (DC 6V)
    Location of Manufacture Japan

    Battery BOX

    Model L-BT6
    Battery Primary battery: manganese dioxide lithium battery 2CR5
    Shoe Canon, Nikon, Pentax
    Output DC 5-6 V, 0.36 A
    Input DC 6 V, 0.4 A
    Weight 80 g
    Dimensions 58 mm × 54.5 mm × 21 mm
    Continuous operating time 3.5h

    Lighting Unit

    Input 5-6 V
    Lighting Source White LED 18 pieces
    Electricity Consumption 0.36 A
    Input Connecter Type 2DC Jack: Center (+) polarity
    Polarity of DC Plug Center (+) polarity
    Cable length 0.2 m
    Cable Ampacity 1A MAX

    Specifications and design of the products are subject to change without prior notice.
